- 3½ digits LCD with maximum reading 2000.
- Overload indication.
- Low battery indication.
- According to JISC1609:1993 and CNS 5119 general A class specifications.
- Spectral response close to CIE luminous spectral efficiency.
- Measuring intensities of illumination in unit of Lux or Foot-candle.
- Measuring lights source include all visible range.
- Cosine angular corrected.
Warehouses, factories, office buildings, restaurants, schools, library, hospitals, photographic,video, parking garages, museums, art galleries, stadiums, building security.
Model |
TEN633 |
Data hold |
V |
Max/ Min /AVG hold |
|
Max hold |
V |
Zero adjustment |
V |
Auto ranging |
|
Auto power off |
|
Datalogger |
Sensor |
Silicon photodiode and filter |
|
Measuring range |
200, 2000, 20000, 200000 Lux 20,200, 2000, 20000 Foot-candle |
|
Accuracy |
+/- 3% (Calibrated to standard incandescent lamp 2856º K) +/- 8% (other visible light source TM-204) +/- 6%(other visible light source TM-203/205) |
|
Angle deviation from cosine characteristics |
30º |
+/- 2% |
60º |
+/- 6% |
|
80º |
+/-25% |
DIMENSION
Meter size (LxWxH) |
172x55x38mm |
Weight (including battery) |
250g |
