Display
|
4 digit LCD read out
|
Measuring Range
|
9.999, 99.99, 999.9, 7000 lumens, Auto ranging (4 step)
|
Overrange Display
|
OL is displayed
|
Resolution
|
0.001 lumens
|
Accuracy
|
0.05 to 0.1 ±7%, 0.1 to 1000 ±1%, 1000 to 7000 ±3%
|
Integrating Sphere
|
Diameter
|
50mm
|
Sample pore
|
12.7mm diameter
|
CIE photopic f ’1
|
≦6%
|
Temperature Characteristics
|
±0.1%/℃
|
Measuring Rate
|
Approximately 5 time/sec
|
Photosensor
|
Silicon photodiodes
|
Data Memory Capacity
|
999 sets. (Direct reading from LCD display)
|
Data Logger Capacity
|
40000 sets
|
Operating/Storage Conditions
|
0℃ ~ 50℃ <80% RH , -10℃ ~ 60℃ <70%RH
|
Power Source
|
6 pcs AAA size Battery
|
Battery Life (typical)
|
100 hours
|
Integrating sphere Lead Length
|
150 cm (approx.)
|
Integrating sphere Dimensions
|
68(Diameter) × 82(H)mm
|
Dimension
|
150(L) × 72(W) × 35(H)mm
|
Weight
|
470g
|
Accessories
|
Carrying case, Instruction manual, Battery, CD software, RS232 cable, AC adaptor, Adapter kit.
|
|
