Improved Repeatability with Mode S™ Technology. Mode S™ is the solution to fluctuating measurement values. Ideal for fatty and/or dark samples, such as dairy products.
Specifications
Model | PAL-S |
---|---|
Cat.No. | 3860 |
Scale | Brix Temperature |
Measurement Range | Brix : 0.0 to 93.0 % Temperature : 10.0 to 100°C |
Resolution | Brix : 0.1% Temperature : 0.1°C |
Measurement Accuracy | Brix : ±0.2 % Temperature : ±1°C |
Temperature compensation range | 10 to 100 °C (Automatic Temperature Compensation) |
Ambient Temperature | 10 to 40°C |
Sample Volume | 0.3ml |
Measurement Time | 60 seconds of continuous measurement after 5 to 15 seconds of analysis |
Power Supply | 2 × AAA Batteries |
Battery Life | Approximately 1,500 measurements (60 seconds of continuous measurement after 5 to 15 seconds of analysis) |
International Protection Class | IP65 Dust-tight and Protected against water jets. |
Included Accessories | MAGIC™: RE-39411 |
Dimensions & Weight | 55(W)×31(D)×109(H)mm, 100g (Main Unit only) |
Options
· PAL-CASE : RE-39409
· STRAP : RE-39410
· 10% Sucrose (±0.03%) : RE-110010
· 20% Sucrose (±0.03%) : RE-110020
· 30% Sucrose (±0.03%) : RE-110030
· 40% Sucrose (±0.04%) : RE-110040
· 50% Sucrose (±0.05%) : RE-110050
· 60% Sucrose (±0.05%) : RE-110060
Patent for Invention Registration No. ZL200310103015.2 (China)
Patent for Design Registration No. ZL03303431.1 (China), 089244 (Taiwan)
Patent Granted in countries around the world.
