● 2000 counts.
● DC Voltage measurement.
● 4-wire resistance measurement.
● Data hold function.
● Low battery indication.
● 9V DC power supply.
● Measure battery types: Li-ion, Ni-Cd, Ni-MH
● Simple operation.
● Lead resistance and contact resistance eliminated.
DC Voltage | ||
Range | : | 2V / 20V / 100V |
Resolution | : | 1mV / 10mV / 100mV |
Accuracy | : | ±(1%rdg+1dgt) / ±(1%rdg+1dgt) / |
±(1%rdg+1dgt) | ||
Resistance | ||
Range | : | 200mΩ / 2000mΩ / 20Ω |
Resolution | : | 0.1mΩ / 1mΩ / 10mΩ |
Accuracy | : | ±(3%rdg+3dgt) / ±(3%rdg+3dgt) / |
±(3%rdg+3 dgt) | ||
General | ||
Low battery | ||
indication | : | " " sign appears on the display when |
the battery voltage drops below accurate | ||
operating level. | ||
Dimensions | : | 192(L) × 88.6(W) × 45.2(D) mm |
Weight | ||
(battery included) | : | Approx. 360g |
Power source | : | 9V(6F22) × 1 |
Safety standard | : | EN 61010-1 CAT I 100V |
EN 61326-1 |
